Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Brand:
BTS EngineeringCharacteristics
Producer:
BTS Engineering
Stationary and rotating face:
SIC/SIC
Seal type:
R-AL.LKHs
Shaft diameter:
32
Rubber type:
EPDM
Material of metal part:
304
Application:
Alfa Laval
See all
Categories
Favorite
Compare
Products from the same category
Mechanical seals Alfa Laval R-AL.LKHs 32, CAR/SIC, EPDM, 304
In stock
$112.11
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 316
Pre-order only
$134.53
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, VITON, 304
In stock
$134.53
Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, VITON, 316
Pre-order only
$147.90
Mechanical seals Alfa Laval R-AL.LKHs 42, CAR/SIC, EPDM, 304
In stock
$162.84
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cardsFeatures Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Producer | BTS Engineering |
Stationary and rotating face | SIC/SIC |
Seal type | R-AL.LKHs |
Shaft diameter | 32 |
Rubber type | EPDM |
Material of metal part | 304 |
Application | Alfa Laval |
Analogue for | Hermetica М112К.AL1, Vulcan 92B |
Gross weight, kg | 0.25 |
Length of transport packing, cm | 8 |
Width of transport packing, cm | 8 |
Height of transport packing, cm | 10 |
Description Mechanical seals Alfa Laval R-AL.LKHs 32, SIC/SIC, EPDM, 304
Single mechanical seal
(Single shaft seal)
It is used in pumps ALFA LAVAL LKH-series:
ALFA LAVAL LKH-5, -10, -15, -20, -25, -35, -40, -50,
-60, -70, -75, -85 and -90.
Planters diameters of shafts 32 (31, 7) and 42 mm
performance materials:
1. The rotating ring: Carbon / SIC
2. Stationary Ring: SIC / TC
3. Bellows: NBR / EPDM / VITON.
4. Metal parts: SS316.
Terms of Use:
• Temperature: -20°С ~ 140°С
• Pressure: ≤1.4 MPa
• Speed: ≤15 m/s
articles:
9611922302 9611922303 9611922304 9611922305 9611922072 9611922073 9611922074 9611922075 9611922080 9611922081 9611922082 9611922083 9611922178 9611922179 9611922180 9611922181
9611922088 9611922089 9611922090 9611922091 9611922522 9611922523 9611922524 9611922525 9611922546 9611922547 9611922548 9611922549 9611922570 9611922571 9611922572 9611922573
9611922594 9611922595 9611922596 9611922597 9611922619 9611922620 9611922621 9611922622
9611922306 9611922307 9611922308 9611922309 9611922114 9611922115 9611922116 9611922117 9611922122 9611922123 9611922124 9611922125
9611922182 9611922183 9611922184 9611922185 9611922130 9611922131 9611922132 9611922133 9611922238 9611922239 9611922240 9611922241
9611922976 9611922977 9611922978
9611922952 9611922953 9611922954 9611922955 9611922867 9611922868 9611922869 9611922870 9611922526 9611922527 9611922528 9611922529
9611922550 9611922551 9611922552 9611922553 9611922574 9611922575 9611922576 9611922577 9611922598 9611922599 9611922600 9611922601
9611922623 9611922624 9611922625 9611922626 9611922643 9611922644 9611922645 9611922646 9611922985 9611922986 9611922987
9611922964 9611922965 9611922966 9611922967 9611922879 9611922880 9611922881 9611922882
9612129609 9612129610 9612129611 9612129612
9612129605 9612129606 9612129607 9612129608
Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.
