Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304

Characteristics
Producer:
BTS Engineering
Stationary and rotating face:
CAR/SIC
Pressure:
1.0 MPa
Operating temperature:
from -20 to +120
Rotation velocity:
15 m/s
Seal type:
R-HLG
Shaft diameter:
19
See all
Ukraine: In stock
Poland: Out of stock
Germany: Out of stock
Code: 17756_19__CAR/SIC__EPDM__304
$81.22 netto
Amount:
Favorite
Compare
We deliver anywhere in the world
product_promo_title_1Exchange or returnWe will return or exchange for another product
product_promo_title_2Fast shippingWe will pick up and send promptly
product_promo_title_3Warranty and qualityGuaranteed return of goods within 10 days
product_promo_title_4On-line payment on the sitePayment is made by bank cards
Features Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304
Producer
BTS Engineering
Stationary and rotating face
CAR/SIC
Pressure
1.0 MPa
Operating temperature
from -20 to +120
Rotation velocity
15 m/s
Seal type
R-HLG
Shaft diameter
19
Rubber type
EPDM
Material of metal part
304
Application
Hilge
Analogue for
AESSEAL T03, Vulcan 12, Roten 2, LIDERING RN / LS60, Latty T900, Flowserve 42, DIMER TCO.121-12, Burgmann BT-RN
Gross weight, kg
0.25
Length of transport packing, cm
8
Width of transport packing, cm
8
Height of transport packing, cm
10
Description Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304
Mechanical seal with R-HLG conical spring and one-way direction of rotation is used at temperatures ranging from -20°C + 120°C, pressures up to 1.0 MPa and a speed of 15 m/s. Application: Pumps Hilge Contra series, Durietta, Euro-Hygia, Hygia. Analogue: DIMER TCO.121-12. Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.
Documentation Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304
Video Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304
Shaft seal Hilge R-HLG 19, CAR/SIC, EPDM, 304 reviews
