Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Brand:
BTS EngineeringCharacteristics
Producer:
BTS Engineering
Pressure:
0,8 MPa
Operating temperature:
20°C +180°C
Rotation velocity:
10 m/s
Seal type:
R-WB3
Stationary and rotating face:
CAR/SIC
Material of metal part:
AISI 304 stainless steel
See all
Documentation
Categories
Favorite
Compare
Products from the same category
Mechanical seal for chemical pump with PTFE bellows R-WB3 25, S, CAR/SIC, VITON, 304
Pre-order only
$166.20
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cardsFeatures Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Producer | BTS Engineering |
Pressure | 0,8 MPa |
Operating temperature | 20°C +180°C |
Rotation velocity | 10 m/s |
Seal type | R-WB3 |
Stationary and rotating face | CAR/SIC |
Material of metal part | AISI 304 stainless steel |
Rubber type | VITON |
Shaft diameter | 25 |
Application | Qeehua |
Description Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal with PTFE bellows R-WB3 - single, unbalanced. For external installation, independent of the direction of rotation of the shaft. It is used at temperatures from - 20ºC to +180ºC, with pressures up to 0.8 MPa and rotational speeds up to 10 m/s.
The R-WB3 mechanical seal is installed on Qeehua's QHB series chemical pumps and other chemical pumps.
Documentation Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Download instructions, catalog for Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Video Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304
Mechanical seal for chemical pump QHB with PTFE bellows R-WB3 25, L, CAR/SIC, VITON, 304 reviews
