CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
Brand:
BTS EngineeringCharacteristics
Output pipe diameter:
1"
Producer:
BTS Engineering
Housing material:
AISI 304 stainless steel
Power supply:
1х220 V, 50 Hz
Max. head, m:
34
Rate of turn, rpm:
2 900
Feed height, m:
34
See all
Documentation
Categories
Favorite
Compare
Products from the same category
Pump for beer wort with pellets TS150, 1.1 kW, AISI 304, 220V/50Hz, 2900 rpm with open impeller
In stock
$303
Pump for pumping kvass, juice, beer, milk TS200, 1.5 kW, AISI 304, 220V/50Hz, 2900 rpm with open impeller
In stock
$327
BTKF 32-160, 2,2 kW, imp.180mm - Cantilever Single Stage Pump (3000)
Pre-order only
$444
Centrifugal pump BB300/110, AISI304, 380V/50Hz, 2900
In stock
$313
Also buy with this product
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cardsFeatures CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
Output pipe diameter | 1" |
Producer | BTS Engineering |
Housing material | AISI 304 stainless steel |
Power supply | 1х220 V, 50 Hz |
Max. head, m | 34 |
Rate of turn, rpm | 2 900 |
Feed height, m | 34 |
Dimensions, mm | 390x250x280 |
Power capacity, kW | 1,5 |
Protection | IP44 |
Pump capacity, m3/h | 11.4 |
Explosion protection | No |
Seal | Mechanical Seal, CER/CAR |
Max.flow rate, m3/h | 11.4 |
Max.temperature, C | 60 |
Suction capacity (NPSH), m | 9 |
Input pipe diameter | 1 1/4" |
Material | AISI 304 stainless steel |
Serial number of the pump | CPS |
Country of Origin | China |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Type of configuration | with engine |
Application | heating, beer, air conditioning, irrigation, water, water supply, milk, guilt, glaze |
Gross weight, kg | 16.5 |
Description CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS series pumps are single-stage centrifugal pumps suitable for both domestic and industrial applications for pumping clean liquids without solids in agriculture, in technological processes for pumping liquids with weak solutions of acids and alkalis, for wine, beer, milk, for use in heating systems, water supply and for pumping non-aggressive chemicals. Hydraulic characteristics consist in higher head and lower performance. Operating conditions: liquid temperature up to 60°C, ambient temperature up to 40°, total suction height up to 9 m.
Documentation CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
Download instructions, catalog for CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20)
CPS36S stainless steel pump, 1.5 kW, AISI 304, 220 V/50 Hz, 2900 rpm, for moderately aggressive or food-grade liquids (similar to the Ebara CDXM 120/20) reviews
