High-precision polymer dosing pump ATLAS DOS 12.2-05-WIFI-0.50HP-5.47-2800-80-A-NBR
Brand:
AlphaDynamicCharacteristics
Output pipe diameter:
G1 1/4
Producer:
AlphaDynamic
Housing material:
AISI 316 stainless steel
Stator material:
NBR
Power supply:
3х380 V, 50 Hz
Rotor material:
AISI 316 stainless steel
Screw speed, rpm:
500
See all
Documentation
Categories
Favorite
Compare
Products from the same category
Also buy with this product
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cards
Features High-precision polymer dosing pump ATLAS DOS 12.2-05-WIFI-0.50HP-5.47-2800-80-A-NBR
Output pipe diameter | G1 1/4 |
Producer | AlphaDynamic |
Housing material | AISI 316 stainless steel |
Stator material | NBR |
Power supply | 3х380 V, 50 Hz |
Rotor material | AISI 316 stainless steel |
Screw speed, rpm | 500 |
Max. head, m | 120 |
Rate of turn, rpm | 2 800 |
Feed height, m | 120 |
Power capacity, kW | 0,37 |
Pump capacity, cu.m/hour | 0.236 |
Explosion protection | No |
Max.flow rate, m3/h | 0.236 |
Flow rate, l/h | 236 |
Max.temperature, C | 100 |
Pressure, bar | 4 |
Input pipe diameter | G1 1/4 |
Material | AISI 316 stainless steel |
Serial number of the pump | ATLAS DOS |
Country of Origin | Greece |
PumpType | screw type |
Drive Type | electric |
Installation Type | horizontal |
Application | wastewater treatment programs, dosing of additives when mixing lubricants, adhesive dosage, dosages of chemicals, sampling, high-precision dosing of polymers |
Description High-precision polymer dosing pump ATLAS DOS 12.2-05-WIFI-0.50HP-5.47-2800-80-A-NBR
The ATLAS DOS series of screw and metering pumps is the ideal solution for low-flow pumping units that require high volume control accuracy and are offered at an affordable price. These pumps provide pumping of liquids with a low and high degree of viscosity, as well as pumping of abrasive liquids.
Functions: uninterrupted flow of pumped liquid; close and precise connections; no ripple; no check valves; suitable for small rooms; withstands high discharge pressure; reverse pumping direction.
Industrial use: performing waste treatment tasks; high-precision pumping of polymer raw materials; sampling/dosing application; high-precision pumping of polymer raw materials; chemical dosing for production purposes; application for measuring and manufacturing glue; additive dosing in oil mixing tasks; application for municipal wastewater treatment.
Documentation High-precision polymer dosing pump ATLAS DOS 12.2-05-WIFI-0.50HP-5.47-2800-80-A-NBR
Download instructions, catalog for High-precision polymer dosing pump ATLAS DOS 12.2-05-WIFI-0.50HP-5.47-2800-80-A-NBR
