Diaphragm Electromagnetic metering pump PDE HC151-7 PH-RX 20-03/25-02/35-00 230V PP-GL-VT
Brand:
AQUACharacteristics
Producer:
AQUA
Input 4-20 mA:
So
Output service relay:
No
Power supply:
1х220 V, 50 Hz
Power capacity, Wt:
22
Control:
Microprocessing
Pulse input(From Flowmetwer):
No
See all
Categories
Favorite
Compare
Products from the same category
Also buy with this product
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cards
Features Diaphragm Electromagnetic metering pump PDE HC151-7 PH-RX 20-03/25-02/35-00 230V PP-GL-VT
Producer | AQUA |
Input 4-20 mA | So |
Output service relay | No |
Power supply | 1х220 V, 50 Hz |
Power capacity, Wt | 22 |
Control | Microprocessing |
Pulse input(From Flowmetwer) | No |
Support for flow sensor | No |
Hose standard size | 4x6 |
Input foe sensor PH | So |
Model | pH-Rx |
Input for sensor RX | So |
Pump head type | Polypropylene 1/2 " |
Flow rate, l/h | 35 |
Dosage mode: Continually ON-OFF | So |
Input foe sensor | No |
Pressure, bar | 3 |
Pump body material | Polypropylene |
Dosage mode: proportional PROP | So |
Input for sensor CD | No |
Product regulation 0-100% | So |
Input foe temperature sensor | No |
Material | PP |
Input for level sensor reagent | So |
Input mA | So |
Number of pulses | 300 |
Serial number of the pump | HC151 |
Country of Origin | Italy |
PumpType | dosing solenoid |
Drive Type | electric |
Application | algicide, hypochlorite, acids, of hydrochloric acid, alkalis, caustic, coagulant |
Weight, kg | 2,86 |
Description Diaphragm Electromagnetic metering pump PDE HC151-7 PH-RX 20-03/25-02/35-00 230V PP-GL-VT
Membrane electro-magnetic dosing pump HC151 pH Rx.
Digital dosing pump for continuous abnormal proportional dosing with a built-in pH controller (from 0 to 14) or Red / Ox potential (from 0 to 999 mV). Control by signal (4-20 mA) from the signal pH sensor or Red / Ox potential (not included in the delivery set). Low regulation of the frequency of the piston stroke (0 ... 100% or 0 ... 20%), the ability to connect the level sensor in the monitor.
HC151 is a digital metering pump, which is efficient in a continuous mode, as well as in a proportional one, as a signal. At the lower part of the pump, there are roses for additional input and output signals (level sensor, impulse water heater, flow sensor, analog signal 4-20 mA, output relay). When the pump display is on, a menu of the operator with information about the robot mode is displayed on the new one, you can start and pause. Thanks to the digital controller and the alphanumeric display, this pump is very simple and convenient in use.
Overall dimensions (height x width x length) - 220 x 128 x 153 mm.
Weight - 3 kg.
