Gear pump JKRN 400 L 4 inches, 50 m3/h, CI cast iron casing, with 11 kW motor, 380V, 1140 rpm
Brand:
ShivayCharacteristics
Output pipe diameter:
4"
Producer:
Shivay
Housing material:
Сast iron
Power supply:
3х380 V, 50 Hz
Rate of turn, rpm:
1 440
Power capacity, kW:
11
Pump capacity, m3/h:
36
See all
Documentation
Categories
Favorite
Compare

Products from the same category
Also buy with this product




Features Gear pump JKRN 400 L 4 inches, 50 m3/h, CI cast iron casing, with 11 kW motor, 380V, 1140 rpm
Output pipe diameter | 4" |
Producer | Shivay |
Housing material | Сast iron |
Power supply | 3х380 V, 50 Hz |
Rate of turn, rpm | 1 440 |
Power capacity, kW | 11 |
Pump capacity, m3/h | 36 |
Flow rate, l/min | 600 |
Seal | gland packing |
Max.temperature, C | 200 |
Shaft material | AISI 8620 |
Pressure, bar | 10 |
Gear meshing type | external |
Input pipe diameter | 4" |
Material | cast iron |
Serial number of the pump | JKRN |
Country of Origin | India |
PumpType | gear type |
Installation Type | horizontal |
Type of configuration | with engine |
Description Gear pump JKRN 400 L 4 inches, 50 m3/h, CI cast iron casing, with 11 kW motor, 380V, 1140 rpm
Шестеренчасті насоси Shivay серії JKRN використовуються для перекачування в'язких або напівв'язких рідин.
Шестеренні насоси добре відомі і широко застосовуються в різних галузях промисловості завдяки своїй ефективній роботі, експлуатаційній надійності, компактній конструкції та безшумній роботі. Доведена продуктивність і економічність - головні чинники, які слід враховувати при оцінці потреб у перекачуванні. Приклади застосування шестеренчастих насосів: електростанції, металургійні, цементі, бітумні заводи, нафтова промисловість, нафтопереробні заводи, насосні станції, всі види навантаження і розвантаження рідин.
Documentation Gear pump JKRN 400 L 4 inches, 50 m3/h, CI cast iron casing, with 11 kW motor, 380V, 1140 rpm
Download instructions, catalog for Gear pump JKRN 400 L 4 inches, 50 m3/h, CI cast iron casing, with 11 kW motor, 380V, 1140 rpm
