WILO HELIX V5202-1/16/E/KS/400-50 multi-staged pump
Brand:
WiloCharacteristics
Output pipe diameter:
DN 80
Producer:
Wilo
Impeller material:
AISI 304 stainless steel
Power supply:
3х380 V, 50 Hz
Max. head, m:
56
Feed height, m:
56
Power capacity, kW:
7,5
See all
Categories
Favorite
Compare

Products from the same category
Also buy with this product




Features WILO HELIX V5202-1/16/E/KS/400-50 multi-staged pump
Output pipe diameter | DN 80 |
Producer | Wilo |
Impeller material | AISI 304 stainless steel |
Power supply | 3х380 V, 50 Hz |
Max. head, m | 56 |
Feed height, m | 56 |
Power capacity, kW | 7,5 |
Protection | IP55 |
Pump capacity, cu.m/hour | 80 |
Max.flow rate, m3/h | 80 |
Max.temperature, C | 120 |
Shaft material | AISI 304 stainless steel |
Material of flow channel | AISI 304 stainless steel |
Input pipe diameter | DN 80 |
Material | AISI 304 stainless steel |
Serial number of the pump | Helix |
Country of Origin | Germany |
PumpType | multi-stage |
Drive Type | electric |
Installation Type | vertical |
Type of configuration | with engine |
Application | steam boiler, flushing, water, hot water, pressure increase, water treatment, fountain, hydroponics, membranes, caustic, sinks, irrigation, aeroponics, greenhouses, osmosis, water treatment, alkalis, nozzles, water supply, boiler |
Weight, kg | 128 |
Description WILO HELIX V5202-1/16/E/KS/400-50 multi-staged pump
Multistage centrifugal pump WILO HELIX of vertical design and line connection. This pump is distinguished by highly compacted design. The pump shaft and the IEC motor shaft are connected to each other by a longitudinal-roll coupling. The separate rolling bearing of the connecting element guarantees optimum absorption of axial forces. Applications: water supply and pressure boosting, industrial circulation plants, process water, closed cooling circuits, fire extinguishing systems, washing plants
