Multistage pump CDLF 32-130, AISI 316, Ex
Brand:
BTS EngineeringCharacteristics
Output pipe diameter:
DN65
Producer:
BTS Engineering
Housing material:
AISI 316 stainless steel
Max. head, m:
237
Rate of turn, rpm:
2 900
Feed height, m:
237
Power capacity, kW:
30
See all
Documentation
Categories
Favorite
Compare
![We deliver anywhere in the world](/wa-data/public/site/world-delivery.webp)
Products from the same category
Also buy with this product
![product_promo_title_1](/wa-data/public/site/themes/sealing_en/img/promo-product-1.webp?v1661410361?v3.4.1.1727010459)
![product_promo_title_2](/wa-data/public/site/themes/sealing_en/img/promo-product-2.webp?v1661410361?v3.4.1.1727010459)
![product_promo_title_3](/wa-data/public/site/themes/sealing_en/img/promo-product-3.webp?v1661410361?v3.4.1.1727010459)
![product_promo_title_4](/wa-data/public/site/themes/sealing_en/img/promo-product-4.webp?v1661410361?v3.4.1.1727010459)
Features Multistage pump CDLF 32-130, AISI 316, Ex
Output pipe diameter | DN65 |
Producer | BTS Engineering |
Housing material | AISI 316 stainless steel |
Max. head, m | 237 |
Rate of turn, rpm | 2 900 |
Feed height, m | 237 |
Power capacity, kW | 30 |
Protection | IP55 |
Pump capacity, cu.m/hour | 40 |
Explosion protection | Yes |
Max.flow rate, m3/h | 40 |
Max.temperature, C | 120 |
Material of flow channel | AISI 316 stainless steel |
Input pipe diameter | DN65 |
Material | AISI 316 stainless steel |
Serial number of the pump | CDLF |
Country of Origin | China |
PumpType | multi-stage |
Drive Type | electric |
Installation Type | vertical |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | greenhouses, pressure increase, water treatment, fountain, steam boiler, hydroponics, caustic, sinks, irrigation, aeroponics, water, hot water, flushing, alkalis, osmosis, water supply, boiler, nozzles, water treatment, membranes |
Analogue for | Varna, Grundfos CR, Calpeda MXV, Dab KVC, Aquatica LVR, Lowara SV, VMtec PRIMA VMEV, EBARA EVM, EBARA EVMW, Ebara EVMS, Speroni RVM |
Description Multistage pump CDLF 32-130, AISI 316, Ex
Stainless steel CDLF Series multi-stage pumps. Robust, quiet and easy to operate pumps are applied at municipal, industrial and agricultural facilities, namely in systems of fire-extinguishing, water treatment, irrigation, hot and cold water supply, in heating systems, cooling and air conditioning systems.
CDLF pumps in ATEX design are widely applied in food industry, alcohol industry in particular (for pumping of alcohol-containing liquids)
Documentation Multistage pump CDLF 32-130, AISI 316, Ex
Download instructions, catalog for Multistage pump CDLF 32-130, AISI 316, Ex
