CUBIC diaphragm air pump 15 ECTFE
CUBIC diaphragm air pump 15 ECTFE
CUBIC diaphragm air pump 15 ECTFE
CUBIC diaphragm air pump 15 ECTFE
CUBIC diaphragm air pump 15 ECTFE
Brand:
DEBEMCharacteristics
Output pipe diameter:
3/8"
Producer:
DEBEM
Material of valve seat:
PP
Max. head, m:
70
Feed height, m:
70
Max.air pressure, bar:
7
Pneumatic circuit connection, inch, f:
3/8"
See all
Categories
Favorite
Compare
Products from the same category
Food diaphragm pump 503 FOODBOXER
Pre-order only
$14,944.77
Pharmaceutical diaphragm pump 100 SANIBOXER
Pre-order only
$9,997.49
CUBIC pneumatic pump 15 PP
Pre-order only
$845.38
Pump CUBIC 15 ECTFE ICU15ECNTTED--
Pre-order only
$1,252.62
Pump CUBIC 15 ECTFE ICU15ECNTTEV--
Pre-order only
$1,252.62
Pump CUBIC 15 PP ICU15P-NTAPV--
Pre-order only
$752.77
Also buy with this product
Exchange or returnWe will return or exchange for another product
Fast shippingWe will pick up and send promptly
Warranty and qualityGuaranteed return of goods within 10 days
On-line payment on the sitePayment is made by bank cardsFeatures CUBIC diaphragm air pump 15 ECTFE
Output pipe diameter | 3/8" |
Producer | DEBEM |
Material of valve seat | PP |
Max. head, m | 70 |
Feed height, m | 70 |
Max.air pressure, bar | 7 |
Pneumatic circuit connection, inch, f | 3/8" |
Max.viscosity, cPs | 15 000 |
Model | CUBIC 15 |
Max.dry suction head, m | 4 |
Max.diameter of solid inclusions, mm | 0,5 |
Pump capacity, cu.m/hour | 1.02 |
Flow rate, l/min | 17 |
Max.flow rate, m3/h | 1.02 |
Max.temperature, C | 95 |
Diaphragm material at air side | NBR |
Material of flow channel | ECTFE |
Diaphragm material at water side | PTFE |
Input pipe diameter | 3/8" |
Material | ECTFE |
Material of ball valves | PTFE |
Serial number of the pump | CUBIC |
Country of Origin | Italy |
PumpType | membrane pneumatic |
Drive Type | pneumatic |
Availability of spare parts | yes |
Application | ethylene, ethers, clay, paints, slip, alkalis, acetic acid, nitric acid, phosphoric acid, varnish, phosphates, formalin, phenol, alcohol, reverse osmosis systems, sulfur, hydrogen, peroxide, oleum, saturated amine, urea, carbonate, kaolin slurry, slag, ash, viscous liquids, butane, ammonia |
Analogue for | DEPA М, AGRAL DDE-600, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-60, AGRAL DDE-030, DEPA L, DEPA DB, DEPA РМ (Р), Debem BOXER, DELLMECO DMCX, DELLMECO DM, YAMADA NDP, Duotek AF Zone 2 Atex, DUOTEK SANI, DUOTEK FOOD, AlphaDynamic Ruby, Debem FOODBOXER, WILDEN, AquaViva, Emec, Injecta, Seko, FWT, Graco Husky, ProMinent, Debem SANIBOXER, MILTON ROY, PRODOSE, DOSITEC, Milwaukee, Astralpool, Sera, AQUA, Jesco Pump, Grundfos |
Weight, kg | 1,5 |
Description CUBIC diaphragm air pump 15 ECTFE
Mini diaphragm pump with two membranes CUBIC 15
The main pump 15 possibilities CUBIC
• performance up to 17 l / min; samozakachivanie fluid to 3 m .; work in unconfined mode;
• pumping liquids containing solid, and the insoluble particles of up to 0.5 mm;
• pumping very viscous liquids;
• smooth adjustment of productivity 0-100% by adjusting the air flow;
• Support the work in the "dry run";
• execution barrel pump functions;
• Flameproof structure without the electric pump;
• standard version - certification ATEX II 3 / 3G D IIB T 135 ° C (zone 2);
• possibility of operation in hazardous environments - Certification ATEX II 2 / 2GD c IIB T 135 ° C (zone 1);
• a full immersion in the pumped medium (on request);
• kompaknye size, ease of maintenance.
