Submersible borehole pump 3 inch ATEX 316 TREINCH EX MAXIFILTRO 90 55-18, 380V
Brand:
OFT PumpsCharacteristics
Output pipe diameter:
1"
Producer:
OFT Pumps
Power supply:
3х380 V, 50 Hz
Max. head, m:
46
Rate of turn, rpm:
2 850
Feed height, m:
46
Power capacity, kW:
0,55
See all
Documentation
Favorite
Compare

Products from the same category
Also buy with this product




Features Submersible borehole pump 3 inch ATEX 316 TREINCH EX MAXIFILTRO 90 55-18, 380V
Output pipe diameter | 1" |
Producer | OFT Pumps |
Power supply | 3х380 V, 50 Hz |
Max. head, m | 46 |
Rate of turn, rpm | 2 850 |
Feed height, m | 46 |
Power capacity, kW | 0,55 |
Protection | IP68 |
Pump capacity, cu.m/hour | 3.3 |
Explosion protection | Yes |
Max.flow rate, m3/h | 3.3 |
Max.temperature, C | 40 |
Shaft material | AISI 316 stainless steel |
Height, mm | 1 039 |
Material | AISI 316 stainless steel |
Diameter of pump | 3" (75 mm) |
Serial number of the pump | 316 TREINCH EX MAXIFILTRO 90 |
Country of Origin | Italy |
PumpType | borehole |
Drive Type | electric |
Installation Type | vertical |
Warranty, months | 12 |
Weight, kg | 14,4 |
Description Submersible borehole pump 3 inch ATEX 316 TREINCH EX MAXIFILTRO 90 55-18, 380V
Application of the pump: pumping liquids in landfills, draining liquids from piezometric Wells, sampling liquids in contaminated areas and ground water.
ATEX pumps in accordance with Directive 2014/34 / EC can be installed in explosive environments in accordance with the ATEX marking.
Features: multi-stage centrifugal electric submersible pumps for 3-inch Wells; external pump body, discharge pipe, suction pipe, shaft and other components are made of Aisi 316 stainless steel; impellers and diffusers made of special technopolymer; temperature of the pumped liquid: no more than + 40 °C; available version for permanent immersion in bicarbonates (our ID EX series); available version with Maxi filter 90 or with inclined riser.
Motor: 2-pole asynchronous motor, 50 Hz, 2850 rpm.; Class F insulation; IP68 protection; operating voltage: single-phase 220V, three-phase 380V.
Accessories: control panel, intrinsically safe module with ATEX power supply circuit, ATEX electronic level sensor (or ATEX ID), TPE-E 4g1.5 cable.
Documentation Submersible borehole pump 3 inch ATEX 316 TREINCH EX MAXIFILTRO 90 55-18, 380V
Download instructions, catalog for Submersible borehole pump 3 inch ATEX 316 TREINCH EX MAXIFILTRO 90 55-18, 380V
