JL 65T Centrifugal pump

JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
JL 65T Centrifugal pump
Brand:
BTS Engineering
0 Comment
Characteristics
Output pipe diameter:
DN65
Producer:
BTS Engineering
Power supply:
3х380 V, 50 Hz
Net weight,kg:
39
Max. head, m:
21
Feed height, m:
21
Power capacity, kW:
2,2
See all
Documentation
Categories
Pumps in-line, Centrifugal industrial pumps, Pumps for water supply, Pumps inline heating water supply
Ukraine: Out of stock
Poland: Out of stock
Germany: Out of stock
Code: 1004495
$671.55 netto
Amount:
Favorite
Compare
We deliver anywhere in the world
Products from the same category
Circulation pump in-line WILO IPL 80/145-5,5/2 Circulation pump in-line WILO IPL 80/145-5,5/2
Pre-order only
$2,119.04
JL 50T Centrifugal pump JL 50T Centrifugal pump
Pre-order only
$540.56
Circulation pump in-line WILO IPL 80/155-7.5/2 Circulation pump in-line WILO IPL 80/155-7.5/2
Pre-order only
$2,490.15
Circulation pump in-line WILO IPL 80/140-4/2 Circulation pump in-line WILO IPL 80/140-4/2
Pre-order only
$1,482.77
Circulation pump in-line WILO IPL 65/130-3/2 Circulation pump in-line WILO IPL 65/130-3/2
Pre-order only
$1,311.82
JL 32T Centrifugal pump JL 32T Centrifugal pump
Pre-order only
$347.73
Also buy with this product
Pump Сontroller Y1-4000D, ABS plastic, 3-phase 380V-415V, 0,75-4kW Pump Сontroller Y1-4000D, ABS plastic, 3-phase 380V-415V, 0,75-4kW
$123.52
DN25 Pneumatically actuated control valve 10P11Y-DNx2516Z-L112C-C (CF8 body, SS304 seat) with YT-1000 positioner, 4-20mA input, Ex DN25 Pneumatically actuated control valve 10P11Y-DNx2516Z-L112C-C (CF8 body, SS304 seat) with YT-1000 positioner, 4-20mA input, Ex
$2,156.03
Pump Сontroller 20Y-3000, ABS plastic, 1-phase 220V-240V, 0,37-3kW Pump Сontroller 20Y-3000, ABS plastic, 1-phase 220V-240V, 0,37-3kW
$82.35
PN16 DN80 Stainless steel ball valve AISI 316, seat PTFE PN16 DN80 Stainless steel ball valve AISI 316, seat PTFE
$365.65
Control panel for pump, 4 kW Control panel for pump, 4 kW
$427.46
PN16 DN200 Butterfly valve, body and disc made of stainless steel AISI 304, Seat PTFE PN16 DN200 Butterfly valve, body and disc made of stainless steel AISI 304, Seat PTFE
$309.30
Control panel for pump, 1.5 kW Control panel for pump, 1.5 kW
$225.79
Pump Сontroller Y1-7500D, ABS plastic, 3-phase 380V-415V, 1,1-7,5 kW Pump Сontroller Y1-7500D, ABS plastic, 3-phase 380V-415V, 1,1-7,5 kW
$131.26
Pump Сontroller Y1-11000D, ABS plastic, 3-phase 380V-415V, 1,1-11kW Pump Сontroller Y1-11000D, ABS plastic, 3-phase 380V-415V, 1,1-11kW
$141.53
Pump Сontroller Y1-15000D, ABS plastic, 3-phase 380V-415V, 2,2-15 kW Pump Сontroller Y1-15000D, ABS plastic, 3-phase 380V-415V, 2,2-15 kW
$164.70
Control panel for pump, 3 kW Control panel for pump, 3 kW
$415.77
Pump Сontroller Y1-18500D, ABS plastic, 3-phase 380V-415V, 3-18,5kW Pump Сontroller Y1-18500D, ABS plastic, 3-phase 380V-415V, 3-18,5kW
$200.71
DN50 Thermodynamic flanged condensate trap PN16/1.0619 DN50 Thermodynamic flanged condensate trap PN16/1.0619
$483.25
Pump Сontroller Y1-22000D, ABS plastic, 3-phase 380V-415V, 4-22kW Pump Сontroller Y1-22000D, ABS plastic, 3-phase 380V-415V, 4-22kW
$236.74
Control panel for pump, 5.5 kW Control panel for pump, 5.5 kW
$441.80
Control panel for pump, 2.2 kW Control panel for pump, 2.2 kW
$301.99
Control panel for pump, 7.5 kW Control panel for pump, 7.5 kW
$448.62
DN40 Thermodynamic flanged condensate trap PN16/1.0619 DN40 Thermodynamic flanged condensate trap PN16/1.0619
$422.86
Control panel for pump, 22 kW Control panel for pump, 22 kW
$1,724.41
Control panel for pump, 11 kW Control panel for pump, 11 kW
$463.25
Control panel for pump, 18.5 kW Control panel for pump, 18.5 kW
$748.87
PN16 DN65 Butterfly valve, body and disc made of stainless steel AISI 304, Seat PTFE PN16 DN65 Butterfly valve, body and disc made of stainless steel AISI 304, Seat PTFE
$62.01
Control panel for pump, 15 kW Control panel for pump, 15 kW
$620.95
PN16 DN40 Butterfly valve, cast iron body, AISI 304 disc, Seat EPDM PN16 DN40 Butterfly valve, cast iron body, AISI 304 disc, Seat EPDM
$22.57
PN16 DN65 Stainless steel ball valve AISI 316, Seat: PTFE PN16 DN65 Stainless steel ball valve AISI 316, Seat: PTFE
$292.50
product_promo_title_1Exchange or returnWe will return or exchange for another product
product_promo_title_2Fast shippingWe will pick up and send promptly
product_promo_title_3Warranty and qualityGuaranteed return of goods within 10 days
product_promo_title_4On-line payment on the sitePayment is made by bank cards
Features JL 65T Centrifugal pump
Output pipe diameter
DN65
Producer
BTS Engineering
Power supply
3х380 V, 50 Hz
Net weight,kg
39
Max. head, m
21
Feed height, m
21
Power capacity, kW
2,2
Pump capacity, cu.m/hour
37
Max.flow rate, m3/h
37
Nom.pressure, Mpa
1,6
Max.temperature, C
120
Material of flow channel
cast iron
Input pipe diameter
DN65
Material
cast iron
Serial number of the pump
JL
Country of Origin
China
PumpType
in-line
Drive Type
electric
Installation Type
vertical
Availability of spare parts
yes
Warranty, months
12
Application
glycol, coolant, hot water supply, ethylene glycol, water supply, cooling, air conditioning systems, hot water supply, heating, ice water, cooling towers, glaze, drying, circulation, drying chamber, recycling water supply, pressure increase, hot water, water, boiler, water supply
Analogue for
EBARA LPS, SPRUT 3VP, SPRUT GPD, Speroni SCR, WILO TOP-S, WILO CronoLine-IL-E, WILO VeroLine-IPL, EBARA EGO EASY, PSPRUT 3VP, Grundfos UPS, DAB DCP-G, DAB DCP, DAB CP-G, DAB CP, DAB DCM-G, SPRUT 1V, KSB Etaline, DAB CM-G, KSB Calio, CALPEDA NM, CALPEDA NR, CALPEDA NC, KSB Etaline-R, KSB Etanorm, KSB Calio S, DAB DCM, DAB CM, DAB DKLP, DAB DKLM, DAB KLP, DAB KLM, DAB ALP, DAB ALM
Description JL 65T Centrifugal pump
Flange-type centrifugal pumps are applied in sealed and open vented heating systems with forced coolant circulation. Medium doesn’t come in contact with the pump motor in comparison to the pumps with wet rotor. Inlet and discharge pipes of JL centrifugal pumps are parallel to each other with the similar nominal bores. The JL pumps are equipped with standard flange-type electric air-cooled motors.
Documentation JL 65T Centrifugal pump

Download instructions, catalog for JL 65T Centrifugal pump
