Chemical pump QHB-50032 GFRPP, 520L/min, 19m, 380V, ABLE Motor, centrifugal self-priming

Brand:
Qeehua
Characteristics
Output pipe diameter:
50
Producer:
Qeehua
Power supply:
3х380 V, 50 Hz
Max. head, m:
19
Feed height, m:
19
Power capacity, kW:
2,2
Pump capacity, cu.m/hour:
31.2
See all
Ukraine: Out of stock
Poland: Out of stock
Germany: Out of stock
Code: 1035583
$1,105.74 netto
Amount:
Favorite
Compare
We deliver anywhere in the world
Also buy with this product
product_promo_title_1Exchange or returnWe will return or exchange for another product
product_promo_title_2Fast shippingWe will pick up and send promptly
product_promo_title_3Warranty and qualityGuaranteed return of goods within 10 days
product_promo_title_4On-line payment on the sitePayment is made by bank cards
Features Chemical pump QHB-50032 GFRPP, 520L/min, 19m, 380V, ABLE Motor, centrifugal self-priming
Output pipe diameter
50
Producer
Qeehua
Power supply
3х380 V, 50 Hz
Max. head, m
19
Feed height, m
19
Power capacity, kW
2,2
Pump capacity, cu.m/hour
31.2
Max.flow rate, m3/h
31.2
Max.temperature, C
70
Input pipe diameter
50
Material
GFRPP
Serial number of the pump
QHB
Country of Origin
China
PumpType
console
Drive Type
electric
Installation Type
horizontal
Type of configuration
with engine
Weight, kg
26
Description Chemical pump QHB-50032 GFRPP, 520L/min, 19m, 380V, ABLE Motor, centrifugal self-priming
Chemical centrifugal self-suction pumps of the QHB series are made of materials (GFRPP or PVDF) that can withstand most acid and alkali solutions. QHB is a centrifugal pump with mechanical compaction, direct drive from an electric motor and self-suction function. (Self-suction height 5 M.) The Pump has a powerful self-suction force and is equipped with an idling protection device. The liquid temperature that the pump can pump for GFRPP is up to 80°C, for PVDF material up to 100°C. The inlet flange and self-suction chamber are cast under pressure as a single whole, without any points of welding or connections. The pressure flange and housing are also cast under pressure as a single unit without any welds, which increases the durability of the product and prevents leakage. The pump can pump liquids containing suspended particles. The electric motor is equipped with a microelectronic device to protect against idling, overload, and phase breakage.
Documentation Chemical pump QHB-50032 GFRPP, 520L/min, 19m, 380V, ABLE Motor, centrifugal self-priming

Download instructions, catalog for Chemical pump QHB-50032 GFRPP, 520L/min, 19m, 380V, ABLE Motor, centrifugal self-priming
